仿威圖機柜顯而易見就是仿照德國威圖機柜的產品。除上述，還有一些特點可以區分真仿威圖機柜。
The imitation Rittal cabinet is obviously a product modeled on the German Rittal cabinet. In addition to the above, there are some features that can distinguish between genuine and imitation Rittal cabinets.
一.商品美觀性。機柜從工業品的運用和外觀上都尋求完滿的理念，從鈑金構造規劃和附件的調配運用也非常合理科學，形成了標準化的配套規劃；
1、 Product aesthetics. The cabinet seeks the perfect concept from the application and appearance of industrial products, and the sheet metal structure planning and the deployment and application of accessories are also very reasonable and scientific, forming a standardized supporting planning;
二.運用便利性。內部的縱梁、立柱、橫梁、走線條及自身的模塑化孔的規劃使得用戶裝置都顯得得心應手、便利自若；
2、 Ease of use. The planning of internal longitudinal beam, column, beam, walking line and its own molding hole makes the user's device easy and convenient;
三.健壯耐用、可靠性。構造構造使得構造穩固，單柜大可承重2000KG，不懼裝置任何粗笨器材；
3、 Robust, durable, safe and reliable. The structure makes the structure stable. The maximum load of a single cabinet is 2000kg, and it is not afraid to install any bulky equipment;
四.仿威圖柜從資料上別離碳鋼和不銹鋼，料厚默許為門板2.0mm，裝置板2.5mm，柜體1.5mm；
4、 The imitation Rittal cabinet is separated from carbon steel and stainless steel in terms of data. The tacit material thickness is 2.0mm for door plate, 2.5mm for device plate and 1.5mm for cabinet body;
五.仿威圖柜碳鋼的外表處理默許為噴塑處理，噴塑前做磷化底涂處理，色彩為RAL7035，不銹鋼的外表處理默許技術為拉絲處理。
5、 The surface treatment of carbon steel of imitation Rittal cabinet is tacitly approved to be plastic spraying treatment. Before plastic spraying, phosphating primer treatment is carried out with the color of ral7035. The surface treatment of stainless steel is tacitly approved to be wire drawing treatment.
威圖機柜從構造上可分為：ES柜（五折型材柜），PS柜（九折型材柜），TS柜（十六折型材柜），威圖的柜子表面處理要求很高的防護等級也高,特色即是威圖柜是選用型材構造構造，先將柜子的構造焊接好，然后頂板、底板、側板、門板、裝置板用螺絲固定在構造上，這樣的優點即是商品模塊化構造，運用便利。
Rittal cabinet can be divided into es cabinet (50% off profile cabinet), PS cabinet (10% off profile cabinet) and TS cabinet (16% off profile cabinet). Rittal cabinet requires high surface treatment and high protection level. The feature is that Rittal cabinet adopts profile structure. Firstly, the structure of the cabinet is welded, and then the top plate, bottom plate, side plate, door plate and device plate are fixed on the structure with screws, This advantage is the commodity modular structure and convenient use.
